Ford Courier AHD Camera Kit with 6.86" IPS Mirror Monitor

Ford Courier AHD Camera Kit with 6.86" IPS Mirror Monitor.

Vehicle compatibility

• Ford Transit Courier (N3P), October 2023–2025
• Ford E-Transit Courier (N3P), March 2025–2025
• Ford Tourneo Courier and E-Tourneo Courier (N1P), 2023–2025

Check the original brake light housing dimensions and mounting position before ordering.

Features and specifications

• AHD 720P CMOS camera; 130° horizontal view; IP69
• Night vision approximately 10.5m; PAL/NTSC; DC 12V camera power
• 6.86-inch IPS mirror monitor, 1280 × 480 resolution, 500cd/m² brightness
• Dual video inputs compatible with AHD 720P signals
• Split-screen and automatic reversing full-screen mode
• Monitor DC 12V; operating temperature −20°C to +60°C

Package contents

• Brake light camera
• 6.86-inch mirror monitor and monitor power cable
• Video extension cable and DC power cable
• Female-to-female adapter
• Mounting bracket
• User manual

SKU: ERG-S140/AHD-1+ERG-6002AV-1
